Loulou Deck Mounted Handle

The Loulou deck mounted handle is available in over 300 colors. Its distinctive octagonal body and handle define this contemporary handle.

REQUEST INFORMATION

Loulou Deck Mount Handle Left and Right Collection
Loulou Deck Mount Handle Collection
Loulou Deck Mount Handle Collection
Loulou Deck Mount Handle Collection
Loulou Deck Mount Handle Collection

Share

Description

Loulou Deck Mounted Handle 1/2″



HALLMARKS & COMPONENTS
TECHNICAL INFORMATION
  • A fundamental and feminine handle dedicated to the Spirit of Women
  • Deck mounted ½” valve included
  • The handle turns ¼ to the right
  • Total height: 2⅝”
  • Width: Diameter 2⅛” at Handle
  • Available in flat  enameled finishes
  • All colors of RAL are available
  • Flow rate : 1.2 GPM ( 4,5L/min) at 60 PSI (4.1 Bar)
  • Valves: ceramic disk
  • Made with low lead brass; includes possible ABS component
  • Ref number: 17106720
  1. Deck maximum thickness: 2”  ( 5 cm )
  2. Hole diameter: 1.1/8” ( 3 cm )
  3. Water pressure maximum: 75 PSI (5 Bars)
  4. Recommended pressure: 60PSI
  5. Connection: wire flex provided; ½” connector
  6. Handle spread: max. 10 inches
  7. Metric threading available on request
  8. Flow rate for outside of USA: inquire
  9. Wall-mounted fitting available
  10. ¾” valves available
  11. Refer to the Flux collection to view all other parts
  12. See technical drawings

Technical Specs

Loulou – Deck mounted handle .5 inch NPT _ 17106720 specifications sheet

Finishes

At Compas we offer a large selection finishes. All our finishes are live and patinate over time. We are environmentally conscious and all our finishes adhere to the highest, strict and controlled ecological standards.

Review all finishes available by clicking here.
